The Schneider Electric ABL2REM24015K is a single-phase power supply designed to convert standard AC line voltage into a stable 24V DC output. This compact and cost-effective unit is ideal for powering a variety of low-current devices in industrial and building automation applications.
Key Features and Specifications
- Input:
- Voltage: 100-240V AC single phase
- Frequency: 47-63 Hz
- Automatic voltage switching allows for global compatibility without manual adjustments.
- Output:
- Voltage: 24V DC ± 1% regulation ensures consistent power delivery for sensitive electronics.
- Current: 1.5A maximum output current caters to low-power applications.
- Power: 35W nominal power rating.
- Design:
- Regulated switching mode technology provides efficient power conversion and minimizes energy loss.
- Natural convection cooling eliminates the need for a fan, making the unit silent and low-maintenance.
- Compact dimensions (99mm x 82mm x 30mm) allow for easy integration into space-constrained enclosures.
- DIN rail or panel mountable for flexible installation options.
- Protection Features:
- Overload hiccup protection (110-160%) safeguards the unit from short-term current surges.
- Overvoltage protection automatically shuts down the power supply in case of excessive voltage spikes.
- Integrated fuse protects against input side faults.
- Certifications:
- CE, EAC, KC, RCM comply with international safety and performance standards.
- EN62368-1 (safety), EN 61000-6-2 (EMC) ensure safe and reliable operation.
Applications
The Schneider ABL2REM24015K power supply is suitable for a wide range of applications requiring a reliable 24V DC power source, including:
- Industrial automation: Powering sensors, controllers, and other low-power industrial devices.
- Building automation: Supplying power to security systems, access control systems, and building automation controllers.
- Machine control: Providing DC power for control circuits and indicator lights in machinery.
- LED lighting systems: Supplying consistent voltage for LED strip lights and small LED fixtures.
- Communication systems: Powering low-voltage communication equipment.
Advantages
- Reliable Performance: Regulated output voltage and overload/overvoltage protection ensure stable and dependable power for connected devices.
- Global Compatibility: Wide input voltage range (100-240V AC) makes it suitable for use in most countries without requiring an additional voltage converter.
- Compact Design: Small footprint allows for easy installation in tight spaces.
- Silent Operation: Fanless cooling minimizes noise generation.
- Cost-Effective: Affordable solution for low-power applications.
- Easy Installation: DIN rail or panel mounting options provide flexibility for different environments.
- Safety Certifications: Meets international safety and electromagnetic compatibility standards for peace of mind.
Considerations
- Output Current: The 1.5A maximum output current limits the power supply to powering low-current devices. Ensure the total current draw of your devices doesn’t exceed 1.5A to avoid overloading the unit.
- Ambient Temperature: The power supply’s efficiency can be impacted by high ambient temperatures. Refer to the Schneider Electric specifications for derating information at elevated temperatures.
- Advanced Features: This is a basic power supply and lacks advanced features like remote monitoring or output voltage adjustment.
Conclusion
The Schneider Electric ABL2REM24015K is a versatile and reliable single-phase power supply ideal for powering a variety of low-current DC devices in industrial and building automation applications. Its compact size, wide input voltage range, and silent operation make it a compelling choice for various low-power projects. However, it’s crucial to consider the unit’s current limitations and ensure it meets the specific power requirements of your application.
